Title: Question About Tsop Flashing
Post by: manxbox44 on December 16, 2004, 01:24:00 PM
i was wondering if you had to keep switching from a 1mb to a 256k each time you wanted to flash a different version of the xbox or will 0.07 raincoat do it for me on its own?


thank you
Title: Question About Tsop Flashing
Post by: acemilo on December 16, 2004, 02:02:00 PM
Raincoat SHOULD fill up the tsop, but I wouldn't risk it, just flash the bios with the proper size.
Title: Question About Tsop Flashing
Post by: JohnnyHunng on December 16, 2004, 02:31:00 PM
Nah, Raincoat .7 will make a 256k bios file a 1mb bios when flashing a 1.0/1.1, no problems there.
Title: Question About Tsop Flashing
Post by: lordvader129 on December 16, 2004, 02:43:00 PM
QUOTE (JohnnyHunng @ Dec 16 2004, 04:34 PM)
Nah, Raincoat .7 will make a 256k bios file a 1mb bios when flashing a 1.0/1.1, no problems there.

yep, just make sure you have raincoat .7, since any older version wont fill by default
Title: Question About Tsop Flashing
Post by: manxbox44 on December 16, 2004, 07:52:00 PM
QUOTE (lordvader129 @ Dec 16 2004, 11:46 PM)
yep, just make sure you have raincoat .7, since any older version wont fill by default

hey lordvader129

so what you are saying is that i can use  raincoat 0.7 with a 2569k or a 1mb to flash any v1.0-1.5?????
Title: Question About Tsop Flashing
Post by: lordvader129 on December 16, 2004, 08:13:00 PM
QUOTE (manxbox44 @ Dec 16 2004, 09:55 PM)
hey lordvader129

so what you are saying is that i can use  raincoat 0.7 with a 2569k or a 1mb to flash any v1.0-1.5?????

.7 with a 256k bios will flash any 1.0-1.5

a 1mb bios will only work on a 1.0 or 1.1 (raincoat will only resize up, not down)
Title: Question About Tsop Flashing
Post by: manxbox44 on December 16, 2004, 08:34:00 PM
QUOTE (lordvader129 @ Dec 17 2004, 05:16 AM)
.7 with a 256k bios will flash any 1.0-1.5

a 1mb bios will only work on a 1.0 or 1.1 (raincoat will only resize up, not down)

ok thanks lordvader129
Title: Question About Tsop Flashing
Post by: manxbox44 on December 16, 2004, 11:07:00 PM
hey  lordvader129

can you link me to a good  tutor ti install a bigger hdd after flashing?
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 02:16:00 AM
QUOTE (manxbox44 @ Dec 17 2004, 05:37 AM)
ok thanks lordvader129

hey


can use this 4981.06_256k.bin one with .7 raincoat to flash v1.0-1.5. also do i need to edit it or anything for it to work?














* if this illegal please delete it
Title: Question About Tsop Flashing
Post by: lordvader129 on December 17, 2004, 11:40:00 AM
http://www.xbox-scen...dd-install2.php

you can skip the eovx disc making if you use slayers


and yes, 4981.06_256k.bin + raincoat .7 is fine for 1.0-1.5
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 03:07:00 PM
QUOTE (lordvader129 @ Dec 17 2004, 08:43 PM)
http://www.xbox-scen...dd-install2.php

you can skip the eovx disc making if you use slayers


and yes, 4981.06_256k.bin + raincoat .7 is fine for 1.0-1.5

ok lordvader129 .........do i need to edit the bios or anything? also i can not put just put the slayers disc in and formmat it and it be ready to go?
Title: Question About Tsop Flashing
Post by: lordvader129 on December 17, 2004, 03:30:00 PM
you only need to edit the bios if you want to change the colors or boot sequence

yes, slayers will format the drive and do everythign for you
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 05:04:00 PM
QUOTE (lordvader129 @ Dec 18 2004, 12:33 AM)
you only need to edit the bios if you want to change the colors or boot sequence

yes, slayers will format the drive and do everythign for you

ok lordvader129
thanks for all your help
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 08:04:00 PM
QUOTE (lordvader129 @ Dec 17 2004, 08:43 PM)
http://www.xbox-scen...dd-install2.php

you can skip the eovx disc making if you use slayers


and yes, 4981.06_256k.bin + raincoat .7 is fine for 1.0-1.5

hey lordvader129

should i name the bios  bios.bin or is it fine the way it's now?
Title: Question About Tsop Flashing
Post by: lordvader129 on December 17, 2004, 09:26:00 PM
QUOTE (manxbox44 @ Dec 17 2004, 10:07 PM)
hey lordvader129

should i name the bios  bios.bin or is it fine the way it's now?

its fine the way it is, youll just have to use the command
QUOTE
./ raincoat -p 4981.06_256k.bin
if you rename it just make sure you use the right command when flashing
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 09:41:00 PM
QUOTE (lordvader129 @ Dec 18 2004, 06:29 AM)
its fine the way it is, youll just have to use the command  if you rename it just make sure you use the right command when flashing

ok will do thanks
Title: Question About Tsop Flashing
Post by: manxbox44 on December 17, 2004, 10:45:00 PM
ok i have been reading alot of posteds and tutorials for a v1.2-1.5 i need to solder 3 points on the board and some say i only need to solder only two . which one is right and what i use? i'm am also reading that in alot of the version of raincoat that i need to add different commands to the raincoat.conf file. do i need to do all of this or has it all been add to raincoat 0.7? i have also heard that you can use the platinum version of 007 AUF but then some say you have to have the older version of 007 AUF to do it? i would be ever so greatful if someone can answer my question that i have.


thankyou
Title: Question About Tsop Flashing
Post by: lordvader129 on December 17, 2004, 11:48:00 PM
user posted image

those are the 2 points you need for 1.2-1.5, top only, no need to take the board out



as for 007, there are actually 3 versions fo the game, original (non platinum), platinum 1, and platinum 2

the original version and platinum 1 work, platinum 2 (newer copies) has been patched so it wont load the hacked save

user posted image
Title: Question About Tsop Flashing
Post by: manxbox44 on December 18, 2004, 07:50:00 AM
QUOTE (lordvader129 @ Dec 18 2004, 08:51 AM)
user posted image

those are the 2 points you need for 1.2-1.5, top only, no need to take the board out



as for 007, there are actually 3 versions fo the game, original (non platinum), platinum 1, and platinum 2

the original version and platinum 1 work, platinum 2 (newer copies) has been patched so it wont load the hacked save

user posted image

ok thanks but i'm am also reading that in alot of the version of raincoat that i need to add different commands to the raincoat.conf file. do i need to do all of this or has it all been add to raincoat 0.7?
Title: Question About Tsop Flashing
Post by: lordvader129 on December 18, 2004, 09:50:00 AM
you will only need to add a command to raincoat .7 if you have an Atmel brand TSOP (i think these showed up on a few 1.4s)

i should just post an updated raincoat.conf for people to use
Title: Question About Tsop Flashing
Post by: manxbox44 on December 18, 2004, 04:03:00 PM
QUOTE (lordvader129 @ Dec 18 2004, 06:53 PM)
you will only need to add a command to raincoat .7 if you have an Atmel brand TSOP (i think these showed up on a few 1.4s)

i should just post an updated raincoat.conf for people to use

thanks and it would be great if you would post a updated raincoat.conf for .7 to use
Title: Question About Tsop Flashing
Post by: manxbox44 on December 18, 2004, 05:14:00 PM
QUOTE (manxbox44 @ Dec 19 2004, 01:06 AM)
thanks and it would be great if you would post a updated raincoat.conf for .7 to use

ok from the looks of the pictures i have seen of already solder points it looks like they just heated up the solder and dipped it in the the to holes of each point and then put some in the middle of the two lil holes or did they heat up the ends of a small piece of soldier and connected the two points?



user posted image
Title: Question About Tsop Flashing
Post by: lordvader129 on December 18, 2004, 07:38:00 PM
what i do is a get a small bead of solder on the iron, then touch the bead between the two points, and usually it sticks enough to bridge them, sometimes the points dont cooperate though
Title: Question About Tsop Flashing
Post by: manxbox44 on December 19, 2004, 02:36:00 PM
is there any way to tell which 007 platinum with out opening up the package?
Title: Question About Tsop Flashing
Post by: manxbox44 on December 21, 2004, 02:59:00 PM
QUOTE(manxbox44 @ Dec 19 2004, 11:39 PM)
is there any way to tell which 007 platinum with out opening up the package?
Title: Question About Tsop Flashing
Post by: lordvader129 on December 21, 2004, 03:09:00 PM
QUOTE(manxbox44 @ Dec 19 2004, 04:39 PM)
is there any way to tell which 007 platinum with out opening up the package?
Title: Question About Tsop Flashing
Post by: manxbox44 on December 21, 2004, 04:11:00 PM
QUOTE(lordvader129 @ Dec 22 2004, 12:12 AM)
i belive those same serial numbers are on the outside of the package, not sure where exactly, but i think the first shipment of the patched (non working) discs had the non-patched serials on the case, so the external ID isnt 100%
Title: Question About Tsop Flashing
Post by: manxbox44 on December 30, 2004, 07:15:00 PM
hey lordvader129

i have a 007 platinum version with the nunbers 1448521 on it. is there any way for that you can tell me if this will work? thanks
Title: Question About Tsop Flashing
Post by: lordvader129 on December 30, 2004, 07:30:00 PM
QUOTE(manxbox44 @ Dec 30 2004, 08:46 PM)
hey lordvader129
Title: Question About Tsop Flashing
Post by: manxbox44 on December 30, 2004, 07:36:00 PM
QUOTE(lordvader129 @ Dec 31 2004, 04:01 AM)
is that on the outside case or on the disc? outside case im assuming, it should work, i think the patched one is 1448531 on the outside
Title: Question About Tsop Flashing
Post by: manxbox44 on December 31, 2004, 09:54:00 AM
QUOTE(manxbox44 @ Dec 31 2004, 04:07 AM)
hey lordvader129
Title: Question About Tsop Flashing
Post by: lordvader129 on December 31, 2004, 12:15:00 PM
they all have numbers, but the patched version has a different number i think, im not sure since i have a non-plat edition
Title: Question About Tsop Flashing
Post by: manxbox44 on December 31, 2004, 12:37:00 PM
QUOTE(lordvader129 @ Dec 31 2004, 08:46 PM)
they all have numbers, but the patched version has a different number i think, im not sure since i have a non-plat edition
Title: Question About Tsop Flashing
Post by: manxbox44 on December 31, 2004, 05:39:00 PM
lordvader129 can you tell me what size solder you and also whats agood type to use?

thanks
Title: Question About Tsop Flashing
Post by: manxbox44 on January 02, 2005, 08:29:00 PM
hey lordvader129


i got a hold of a 007 with raincoat0.5 now can i just delete the things in the raincoat folder and drop in everything from raincoat 0.7 and does this now mean that i have now updated  to raincoat 0.7? am i now good to go?
Title: Question About Tsop Flashing
Post by: lordvader129 on January 02, 2005, 08:38:00 PM
all you have to do is repalce raincoat and raincoat.conf in teh reincoat folder and your updated

and for th solder i use .015 dia. sodler and a 15w radio shack iron
Title: Question About Tsop Flashing
Post by: manxbox44 on January 02, 2005, 09:07:00 PM
QUOTE(lordvader129 @ Jan 3 2005, 05:09 AM)
all you have to do is repalce raincoat and raincoat.conf in teh reincoat folder and your updated
Title: Question About Tsop Flashing
Post by: lordvader129 on January 02, 2005, 09:36:00 PM
my (non plat) copy has 1448511 on the outside and 1448507 on the disc
Title: Question About Tsop Flashing
Post by: manxbox44 on January 02, 2005, 11:56:00 PM
ok guys thanks for the info
Title: Question About Tsop Flashing
Post by: lordvader129 on January 12, 2005, 04:16:00 PM
007 - all non plat and some plat (scroll up to see version numbers)
MA - older non-plat (i believe only versions without the game of the year badge work) no plat work
SC - all versions AFAIK (newer plats might not)
Title: Question About Tsop Flashing
Post by: manxbox44 on January 12, 2005, 07:16:00 PM
hey lordvader129


would it be to much to trouble to ask what you use to clean off the tip of your sodlering iron?

thanks
Title: Question About Tsop Flashing
Post by: lordvader129 on January 12, 2005, 07:33:00 PM
i use radio shack tip tinner and cleaner
Title: Question About Tsop Flashing
Post by: manxbox44 on January 12, 2005, 08:05:00 PM
QUOTE(lordvader129 @ Jan 13 2005, 04:04 AM)
i use radio shack tip tinner and cleaner
Title: Question About Tsop Flashing
Post by: manxbox44 on January 13, 2005, 12:58:00 PM
can some one tell me if there if there is any difference in bios 4981.06 or 4981.67?

thanks
Title: Question About Tsop Flashing
Post by: manxbox44 on January 13, 2005, 08:38:00 PM
hey lordvader129


which one would you say is better for doing a tsop the conductive ink or the sodlering iron?
Title: Question About Tsop Flashing
Post by: manxbox44 on January 13, 2005, 09:29:00 PM
i read that tsop can be flashed more than once but i have also heard that it can only be flashed onces. which one of these are true?

thanks
Title: Question About Tsop Flashing
Post by: manxbox44 on January 20, 2005, 02:44:00 PM
can someone please answer my questions above^^^


thanks
Title: Question About Tsop Flashing
Post by: ruffian on January 21, 2005, 12:59:00 AM
manxbox44:

I personally prefer conductive ink pen over solder. More precise/less risk involved.

As for your bios version question: I think it only matters if you're using an HD larger than 137 gb...
xxxx.06 creates one big E: partition
xxxx.67 creates E: up to 137gb, and remaining space as F:
(i *think* - pls correct me if i'm wrong, or verify)
Title: Question About Tsop Flashing
Post by: lordvader129 on January 21, 2005, 01:11:00 AM
QUOTE(ruffian @ Jan 21 2005, 02:30 AM)
manxbox44:
Title: Question About Tsop Flashing
Post by: manxbox44 on January 21, 2005, 02:22:00 PM
QUOTE(manxbox44 @ Jan 14 2005, 05:09 AM)
hey lordvader129
Title: Question About Tsop Flashing
Post by: lordvader129 on January 21, 2005, 02:43:00 PM
whichever works best for you, personally i prefer soldering, but ink works just as well
Title: Question About Tsop Flashing
Post by: manxbox44 on February 09, 2005, 03:05:00 PM
ok thanks
