[deakphreak]

Ive got a 83850c Lite-on drive that has a date of May so it should be flashable and I have done many types of drives before so I am familiar with the process.  I dont know if it matters, but the HW Version is A0A2 on the drive.

Anyway, ive got the CK3 kit but the eject button does not seem to work on it, when I click the eject, nothing happens.  My computer has an Nforce motherboard and built in sata which has always worked for flashing every other drive.  I boot on my computer with the drive attached but power turned off to the drive.  Once booted, I manually pull out the drive all the way and push it in half way and then turn on the power to the drive and load up Jungle Flasher.  It shows the drive just fine. and click LO83info.  I click on OK about powering on the drive half open.  Then it says to pull out the drive so I manually pull it out all the way and click ok. It reads just fine then asks to power the drive half open again.  I then close the tray power it off and power it on, then power it off and manually pull it out, push half way back in and power the drive and click ok...  Then I pull the tray out all the way again and click ok.  It says everything matches and asks to load the ixtreme which the proceeds to say it is a known bad dump and to try again.

Here is some logs.... I hope someone can shed some light on this and let me know if I am doing something wrong or if maybe this drive will just not work with my computer.


-----------------------------------------------------------------------------------------
-----------------------------------------------------------------------------------------


This is a 32 bit process running on 2 x 32 bit CPUs
PortIO is installed and running.
Found 8 I/O Ports.
Found 2 Com Ports.
Found 11 windows drives A: C: E: G: H: I: J: L: W: Y: Z:
Found 2 CD/DVD drives E: L:

Sending LO83info request to I/O port 0x09F0

............
................
0000: 49 6E 20 44 65 64 69 63 - 61 74 69 6F 6E 20 54 6F In Dedication To
0010: 20 54 68 65 20 42 69 72 - 74 68 20 4F 66 20 4D 61  The Birth Of Ma
0020: 63 6B 61 79 20 4F 6E 20 - 46 65 62 72 75 61 72 79 ckay On February
0030: 20 54 77 65 6C 76 65 20 - 32 30 30 37 20 FF FF FF  Twelve 2007 ...
0040: FF FF FF FF FF FF FF FF - FF FF FF FF FF FF FF FF ................
0050: FF FF FF FF FF FF FF FF - FF FF FF FF FF FF FF FF ................
0060: E1 D9 92 B4 E6 28 EB D0 - 1B 86 F9 B4 18 EC B2 87 .....(..........

............. Extract no.2 matches

0000: 05 80 00 32 5B 00 00 00 - 50 4C 44 53 20 20 20 20 ...2[...PLDS
0010: 44 47 2D 31 36 44 32 53 - 20 20 20 20 20 20 20 20 DG-16D2S
0020: 38 33 38 35 30 43 41 30 - 41 32 44 36 30 39 43 47 83850CA0A2D609CG
0030: 39 32 31 38 31 36 30 30 - 34 50 39 20 20 20 00 00 921816004P9   ..
0040: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................
0050: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................

0000: C0 85 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................
0010: 00 00 00 00 44 36 30 39 - 43 47 39 32 31 38 31 36 ....D609CG921816
0020: 30 30 34 50 39 20 20 20 - 00 00 00 00 00 00 33 38 004P9   ......38
0030: 35 38 43 30 20 20 4C 50 - 53 44 20 20 20 20 47 44 58C0  LPSD    GD
0040: 31 2D 44 36 53 32 20 20 - 20 20 20 20 20 20 20 20 1-D6S2
0050: 20 20 20 20 20 20 20 20 - 20 20 20 20 20 20 00 00               ..
0060: 00 00 00 0B 00 00 00 04 - 00 02 06 00 00 00 00 00 ................
0070: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................
0080: 03 00 78 00 78 00 E3 00 - 78 00 00 00 00 00 00 00 ..x.x...x.......
0090: 00 00 00 00 00 00 00 00 - 02 02 00 00 68 00 00 00 ............h...
00A0: 00 00 00 00 00 00 00 00 - 00 00 00 00 00 00 00 00 ................
00B0: 20 20 00 00                                         ..

0000: 44 36 30 39 43 47 39 32 - 31 38 31 36 30 30 34 50 D609CG921816004P
0010: 39 20 20 20 FF FF FF FF - 39 45 30 38 30 36 36 38 9   ....9E080668
0020: 31 36 44 32 31 34 58 58 - 41 30 FF FF 53 34 50 39 16D214XXA0..S4P9
0030: 35 31 32 30 30 30 30 30 - 30 35 30 32 35 32 00 00 51200000050252..
0040: FF FF FF FF FF FF FF FF - FF FF FF FF 41 32 FF FF ............A2..


Extracted drive key 140F0F1011B5223D79587717FFD9EC3A


Dummy.bin file saved to C:\Dummy.bin

Loading DVDkey source file
Inquiry string found
Identify string found
DVD key found @ 0xA030 key is 140F0F1011B5223D79587717FFD9EC3A
Firmware is a Lite-On Dummy OSIG:
Firmware type is: LO83info Extract

[Ranger72]

That is a known bad dump key.

I remember seeing some threads about this bad dump key but cant remember what the solution is. Try to do a Google or forum search for that drive key and see what you come up with.

[j3ll3]

stop using old versions of Jungleflasher is my advice

there is no solution

[deakphreak]

QUOTE(j3ll3 @ Nov 28 2009, 10:55 AM)

stop using old versions of Jungleflasher is my advice

there is no solution

I am using Jungle Flasher 0.1.67 which is the newest one on their website.

[Ranger72]

QUOTE(deakphreak @ Nov 28 2009, 06:02 AM)

I am using Jungle Flasher 0.1.67 which is the newest one on their website.

It looks like you are doing all the right things. But to be honest I have no idea how to solve your problem.

Have you don other 83850c drives before?

[j3ll3]

140F0F1011B5223D79587717FFD9EC3A is a known bad key... and the newest JF should refuse this key

you are able to use this key?

[Ranger72]

QUOTE(j3ll3 @ Nov 28 2009, 11:47 AM)

140F0F1011B5223D79587717FFD9EC3A is a known bad key... and the newest JF should refuse this key

you are able to use this key?

If he uses that key it will not work. He needs to try and get a proper dump before he flashes anything to the drive.

[deakphreak]

QUOTE(Ranger72 @ Nov 28 2009, 04:36 PM)

It looks like you are doing all the right things. But to be honest I have no idea how to solve your problem.

Have you don other 83850c drives before?

I have not done this type of drive before, it is the first time but have done older Lite-on drives, benq, hitachi and samsung before without problems.

I have not used the key because I know it is a bad key and not sure why I keep getting the key.  It says the Dedication To message and everything so I have no idea why I keep getting the bad key.  I was following up on the drive that you cannot get the key from and thought it was that, but this is a May drive so I am thinking it has to be something else.

[OggyUK]

While bored of thinking of ways to make money from the "scene" I decided to hex your logs into a spare [BARCODE].bin I had from when I sent the files to VGC for Geremia's freekey.....

Using Seacrests OpenKey, with your Encrypted key, AES Key, AES Offset, IV etc

(IMG:http://i330.photobucket.com/albums/l432/OggyBST/XB2S.jpg)

It gave that key.

I dont know much about the decryption routine, but its certainly weird as 140F0F1011B5223D79587717FFD9EC3A key is (in every other case) obtained by decrypting:

Cipher Text of 00000000000000000000000000000000  with an AES key of 00000000000000000000000000000000

As you're aware, this isnt the case for you.

Id try another PC personally, but its REALLY weird you ge that key WITH what seems good ciphertext.

And Jelle, JF will allow that key as source but wont let you spoof it to iX

[deakphreak]

I do not really have another PC to test with, but I guess that is going to be my only option right now. Thanks everyone for the replies, I will try to track down a friend with another PC that I can use.
